Specifications:
SPECIFICATIONS | Units | CAK6140 CAK6140B |
Swing over bed | mm | 400 |
Swing over cross slide | mm | 180 |
Distance between centers | mm | 750/1000/1500/2000/3000 |
Spindle bore | mm | 52,(80 for B) |
Spindle bore taper | - | MT6,(φ90 1:20 for B |
Spindle nose type | - | C6,(D8 for B) |
Spindle speed steps | - | Manual 3 steps (Optional: stepless) |
Spindle speed range | rpm | 21-150,66-500,162-1500 (Optional: 100-1600 ) |
Turret/tool post | - | Electric 4 position |
Tool size | mm | 25 x 25 |
X axis travel | mm | 200 |
Z axis travel | mm | 750/1000/1500/2000/3000 |
X axis rapid traverse | mm/min | 6000 |
Z axis rapid traverse | mm/min | 10000 |
Tailstock quill diameter | mm | 75 |
Tailstock quill taper | - | MT5 |
Tailstock quill travel | mm | 150 |
Main spindle motor | kw | 7.5 |
Coolant pump motor | kw | 0.125 |
Weight for 750 | kg | 2450 |
Weight for 1000 | kg | 2550 |
Weight for 1500 | kg | 2650 |
Weight for 2000 | kg | 3050 |
Weight for 3000 | kg | 3850 |
Dimension for 750 | mm | 2550x1650x1700 |
Dimension for 1000 | mm | 2750x1650x1700 |
Dimension for 1500 | mm | 3250x1650x1700 |
Dimension for 2000 | mm | 3700x1650x1700 |
Dimension for 3000 | mm | 4710x1650x1700 |
