Product main technical specifications:
Model | Units | GHSZ4228 | |
Cutting capability | 0° | mm | 280X280 |
45° | mm | 200x280 | |
Blade speed | m/min | 27、45、69 | |
Blade size | mm | 3850*27*0.9 | |
Main motor power | kw | 3 | |
Hydraulic motor power | kw | 0.55 | |
Coolant pump（w） | w | 40 | |
Work clamping method | - | Hydraulic vise | |
Machine weight | kg | 1600 | |
Overall dimension | mm | 2000*2750*1500 | |
Package Size | mm | 2100*2850*1600 | |
