Features：
extra rigid saw frame design ensures excellent angular accuracy and low vibration when cutting workpieces with very large diameters;
The material support surface features driven feed rollers with extremely high-load capacity ,suitable for very heavy workpiece;
Saw frame lifting adopted double oil cylinder control ,ensuring smooth working;
The heavy saw blade tensioning reduces the workload and helps prevent inaccuracies and premature wear of the saw blade;
One bi-metallic band saw blade and feed roller table are included
Product main technical specifications:
Model | Units | GH4270 | |
Cutting capability | Circular | mm | 700 |
Rectangular | mm | 700x700 | |
Blade speed | m/min | 27、45、69 | |
Blade size | mm | 7200*54*1.6 | |
Main motor power | kw | 7.5 | |
Hydraulic motor power | kw | 2.2 | |
Coolant pump（w） | w | 125 | |
Work clamping method | - | Hydraulic vise | |
Machine weight | kg | 5000 | |
Overall dimension | mm | 3500*1600*2400 | |
Package Size | mm | 3600*1800*2550 | |
