Features：
Solid steel saw frame within a dual-column frame guide
Flat and low profile for easier handling of heavy or large workpiece
Feed of the saw frame is infinitely variable via a hydraulic throttle valve
adjustable saw blade guide ensures good cutting result at any workpiece diameter
Hydraulic workpiece clamping included
Product main technical specifications:
Model | Units | GH4260 | |
Cutting capability | Circular | mm | 600 |
Rectangular | mm | 600x600 | |
Blade speed | m/min | 27、45、69 | |
Blade size | mm | 6630*54*1.6 | |
Main motor power | kw | 5.5 | |
Hydraulic motor power | kw | 1.5 | |
Coolant pump（w） | w | 125 | |
Work clamping method | - | Hydraulic vise | |
Machine weight | kg | 3200 | |
Overall dimension | mm | 3150*1350*2200 | |
Package Size | mm | 3300*1450*2400 | |
