Specification：
SPECIFICATIONS | Units | GMC4220 |
Table size（W*L） | mm | 1800x4000 |
X axis travel | mm | 4200 |
Y axis travel | mm | 2200 |
Z axis travel | mm | 1000 |
Gantry width/passing height | mm | W：2000 / H：1300 |
Table load | t | 9 |
Distance between spindle nose and table surface | mm | 205-1205 |
T slot(number-width*pitch) | - | 9-22*190 |
Spindle taper | - | BT50/155 |
Spindle speed | r/min | 6000 |
Rapid traverse speed | m/min | 12 |
Cutting feed speed | m/min | 8 |
Main motor power | kw | 18.5 |
Tool magazine | Arm 30 | |
Positioning accuracy | mm | X/Y ±0.0075 Z ±0.015 |
Repeat positioning accuracy | mm | ±0.005 |
Overall dimension | mm | 13000x4910x4800 |
Machine weight(about) | t | 34.5 |
