| Specifications | Units | XW5032C |
| Table size | mm | 1370x320/1500X320 |
| T-type slot numbers | mm | 3 |
| Table travel | mm | 860/320/450 |
| Max. load of table | kg | 500 |
| Longitudinal/cross mechanical feed speed | Mm/min | 8 steps 15-370(rapid traverse) |
| Distance between spindle and column | mm | 300 |
| Distance between spindle nose and table surface | mm | 50-450 |
| Spindle taper | 7:42 ISO40 | |
| Spindle speed range | rpm | 12 steps, 34-1100 |
| Max. swivel angle of milling head | ° | ±45 |
| Main motor power | kw | 3/4 |
| Auto feed motor power | kw | 0.75 |
| Lifting motor power | kw | 1.1 |
| Coolant pump motor pwoer | w | 40 |
| Overall dimensions | mm | 1900x1800x2150 |
| Net weight | Kg | 2200 |
