Product main technical Specifications:
Specifications(mm) | ZX7550ZW |
Max. drilling dia.(mm) | 50 |
Max. end milling width(mm) | 100 |
Max. vertical milling dia.(mm) | 25 |
Max.boring dia.(mm) | 120 |
Max. tapping dia.(mm) | M16 |
Distance from spindle nose to table surface(mm) | 90-490 |
Spindle taper | MT4 |
Spindle speed range(r.p.m) | 90-2000(V) 80-1300(H) |
Spindle travel(mm) | 120 |
Table size(mm) | 1000x240 |
Table travel(mm) | 600×230 |
Table feed speed(mm/min) | X:16-480 |
Overall dimensions (mm) | 1280×1285×2080 |
Spindle motor power (kw) | 1.5/2.2(V) 2.2(H) |
Machine weight (kg) | 900/1000 |
