Product main technical parameters:
specifications | Z3040X12 |
Max.drilling dia.(mm)(tensile strength 500-600MPA) | steelΦ32 cast iron Φ40 |
Column dia.(mm) | 240 |
Spindle axis to column generating line(mm) | 330-1200 |
Spindle box horizontal travel(mm) | 870 |
Spindle nose to base surface(mm) | 260-1000 |
Radial arm lifting travel(mm) | 590 |
Spindle travel(mm) | 270 |
Spindle taper | MT4 |
Spindle speed(6 steps)(r/min) | 75 130 240 380 660 1220 |
Spindle feed(3 steps)(mm/r) | 0.10 0.16 0.25 |
Spindle allows max.feed resistance(N) | 6300 |
Radial arm lifting speed (m/min) | 1.3 |
Radial arm rotary angle(°) | + 180 |
Main spindle motor(kw) | 2.2 |
Lifting motor power(kw) | 0.55 |
Coolant pump motor power(kw) | 0.04 |
Machine weight(kg) | 1500 |
Machine size(L*W*H)(mm) | 1800×760×2100 |
