Product main technical specifications:
| Specifications | CD6136BCD6236B | CD6140BCD6240B | CD6145BCD6245B | CD6150BCD6250B | CD6160BCD6260B |
| Max. swing over bed | 360mm | 400mm | 450mm | 500mm | 600mm |
| Max. swing over cross slide | 185mm | 225mm | 285mm | 325mm | 380mm |
| Center Distance | 1000/1500/2000mm | ||||
| Max. swing over gap | 490mm | 530mm | 580mm | 630mm | 730mm |
| Effective length of gap | 260mm | ||||
| Bed Width | 330mm | ||||
| Spindle hole | 65mm | ||||
| Spindle nose | ISO-C6 or ISO-D6 | ||||
| Spindle taper | Metric 70mm | ||||
| Spindle speed | 22-1800(15 steps) | ||||
| Metric threads range | 0.5-28mm(66 kinds) | ||||
| Inch threads range | 1-56/inch(66 kinds) | ||||
| Moudle threads range | 0.5-3.5mm(33 kinds) | ||||
| Diametral threads range | 8-56D.P(33 kinds) | ||||
| Longitudinal feeds range | 0.072-4.038mm/rev(0.0027-0.15 inch/rev)(66 kinds) | ||||
| Cross feeds range | 0.036-2.019mm/rev(0.0013-0.075 inch/rev)(66 kinds) | ||||
| Rapid traveling speed of carriage | 5mm/min | ||||
| Lead screw size:diameter pitch | 35mm/6mm | ||||
| Cross slide travel | 300mm | ||||
| Compound rest travel | 130mm | ||||
| Cross-section size of toolshank | 20x20 | 25x20 | 25x20 | 25x20 | 25x25 |
| Taper of tailstock sleeve | Morse No.5 | ||||
| Dia. of tailstock sleeve | 65mm | ||||
| Travel of tailstock sleeve | 120mm | ||||
| Main drive motor | 4.0kw or 5.5kw or 7.5kw | 7.5kw | |||
| Coolant pump motor | 0.125kw | ||||
| Rapid traverse motor | 0.12kw | ||||
| Size(1000mm) | 2420x1150x1800mm | ||||
| Size(1500mm) | 2920x1150x1800mm | ||||
| Size(2000mm) | 3460x1150x1800mm | ||||
| Weight(1000mm) | 1520/2170kg | 1560/2210kg | 1580/2230kg | 1600/2250kg | 1640/2290kg |
| Weight(1500mm) | 1750/2390kg | 1770/2410kg | 1820/2460kg | 1830/2470kg | 1870/2530kg |
| Weight(2000mm) | 2010/2780kg | 2050/2800kg | 2070/2820kg | 2130/2860kg | |
| Standard accessories |
| 3 jaw chuck |
| Driving plate |
| Center ¢er sleeve |
| Wrenches |
| Oil gun |
| Operation manual |
| Optional accessories |
| Steady rest |
| Follow rest |
| 4 jaw chuck |
| Face plate |
| Thread dial |
| Longitudinal automatic stop |
| Live center |
| Quick change tool post |
| Taper turning attachment |
| 4 position longitudinal automatic trip |
